- (2) E5-2600 v3 & v4
- (16) DDR4 DIMM Slots
- Broadcom 5717 Dual-port 1Gb
- (6) PCIe 3.0 slots.(2) PCIe 3.0 x16; (4) PCIe 3.0 x 8 (x8 speed)
- HPE 12TB SATA 7.2 K LFF HDD
- HPE RDX 4TB USB 3.0 External/ Internal Disk Backup System
- HPE iLO (Firmware HPE iLO4 2.0 or later) with NAND
The HPE ProLiant ML150 Gen9 Server, designed for SMBs, supports up to two Intel Xeon E5-2600 v3/v4 processors in a tower form factor that is rack-mountable. It combines performance, efficiency, and manageability with room for growth. Featuring an embedded SATA HPE Dynamic Smart Array B140i Controller for boot and data, it also supports HPE Smart Array Controllers for enhanced performance and 12 Gb/s SAS, or HPE Smart HBAs for high-performance SAS connectivity in HBA or RAID modes. With a compact 24-inch chassis and built-in ProLiant technologies, it simplifies server deployment and management, boosting productivity and scalability for growing businesses.
Ideal for:
- Cloud Servers
- Corporate IT
- Data Analytics
- Database
- Hyper-Converged infrastructure (HCI)
- Retail Servers
- Virtual Desktop Interface (VDI)
- Virtualization
- Anything as a service (Xaas)
CTO Configuration Support
Need help with the configuration? Contact us today!
| CTO Server [Chassis] | HP ProLiant ML150 Gen9 Non-hot Plug 4LFF Configure-to-order Server |
HP ProLiant ML150 Gen9 Hot Plug 4LFF Configure-to-order Server |
HP ProLiant ML150 Gen9 Hot Plug 8SFF Configure-to-order Server |
|---|---|---|---|
| SKU Number | |||
| Processor | 2 (optional) x HPE Smart Socket Guide | ||
| DIMM Slots | 16 DIMM slots for RDIMM, LRDIMM DDR4 Memory | ||
| Storage Controller | HPE Dynamic Smart Array B140i | ||
| PCIe | 6 Standard (4FH/HL, 2FH/FL) | ||
| Drive Cage - included | 4LFF Non Hot Plug | 4LFF Hot Plug | 8SFF Hot Plug |
| Network Controller | Broadcom 5717 Dual-port 1GbE | ||
| Fans | 2 non hot plug, non-redundant fans | ||
| USB | 2 front, 2 internal, 4 rear | ||
onboard B140i SATA controller
UpgradesSecond Non-hot-plug drive cage (792353-001)
9/10LFF Drive Kit (788567-B21)
Non-Hot-Plug (NHPE) SATA is limited to the B140i controller and SATA drives.H240 12Gb 2-ports Int Smart HBA (726907-B21)
UpgradesSecond 4LFF Hot Plug Drive Cage (725872-B21 - 792351-001)
One H240 Cable Kit (784606-B21) per Drive Cage.8SFF - H240 (726907-B21)
16SFF - P840 (726907-B21)
Upgrades8SFF Hot Plug Drive Cage (725874-B21 - 792352-001)
The P840 requires (2) Mini SAS P440/P840 Cable Kit (784608-B21) for 16 Drives
